PP Deco Sheet : DOUBLING TYPE
Print Data Sheet
Characteristic PP Deco sheet with primer coating for the laminating to the furniture finishing
Surface finish Transparent pp film is laminated with the dyed pp film
Thickness range
Width & Color
0.20mm - 0.50mm
950mm - 1,400mm
various
Properties Test method Value Unit
Thickness
0.20mm - 0.50mm
JIS K6734 ¡¾4 %
Width
allowance
JIS K6734 ¡¾3 mm
Hardness JIS K6734 1.22 g/§¨
Shrinkage
(100¡É 5minutes)
machine direction
transverse direction
JIS K6734 -0.5
0.5
%
%
Tensile strenrgth
machine direction
transverse direction
JIS K6734 3.7
3.2
kg/§±
kg/§±
Elongation
machine drection
transverse direction
JIS K6734 625
615
%
%
Tear strength
machine direction
transverse direction
JIS K6734 15.3
13.3
kg/mm
kg/mm
adhesine   3.88 kgf/25mm
Melt range   120-140 ¡É
Chemical resistance
2% NaoH
MEK
Rubbing over
20 times
No defect
No defect
No defect
No defect
Abrasion 100 ȸ
100 ȸ
100 ȸ
0.6
1.1
3.5
mg
mg
mg
Hardness Pencil test   Good
